ST STM32F2 User Manual

UM1940
HAL TIM Extension Driver
DocID028236 Rev 2
631/1371
4. Configure the TIM in the desired functioning mode using one of the initialization
function of this driver:
HAL_TIMEx_HallSensor_Init and HAL_TIMEx_ConfigCommutationEvent: to use
the Timer Hall Sensor Interface and the commutation event with the
corresponding Interrupt and DMA request if needed (Note that One Timer is used
to interface with the Hall sensor Interface and another Timer should be used to
use the commutation event).
5. Activate the TIM peripheral using one of the start functions:
Complementary Output Compare : HAL_TIMEx_OCN_Start(),
HAL_TIMEx_OCN_Start_DMA(), HAL_TIMEx_OC_Start_IT()
Complementary PWM generation : HAL_TIMEx_PWMN_Start(),
HAL_TIMEx_PWMN_Start_DMA(), HAL_TIMEx_PWMN_Start_IT()
Complementary One-pulse mode output : HAL_TIMEx_OnePulseN_Start(),
HAL_TIMEx_OnePulseN_Start_IT()
Hall Sensor output : HAL_TIMEx_HallSensor_Start(),
HAL_TIMEx_HallSensor_Start_DMA(), HAL_TIMEx_HallSensor_Start_IT().
46.2.3 Timer Hall Sensor functions
This section provides functions allowing to:
Initialize and configure TIM HAL Sensor.
De-initialize TIM HAL Sensor.
Start the Hall Sensor Interface.
Stop the Hall Sensor Interface.
Start the Hall Sensor Interface and enable interrupts.
Stop the Hall Sensor Interface and disable interrupts.
Start the Hall Sensor Interface and enable DMA transfers.
Stop the Hall Sensor Interface and disable DMA transfers.
This section contains the following APIs:
HAL_TIMEx_HallSensor_Init()
HAL_TIMEx_HallSensor_DeInit()
HAL_TIMEx_HallSensor_MspInit()
HAL_TIMEx_HallSensor_MspDeInit()
HAL_TIMEx_HallSensor_Start()
HAL_TIMEx_HallSensor_Stop()
HAL_TIMEx_HallSensor_Start_IT()
HAL_TIMEx_HallSensor_Stop_IT()
HAL_TIMEx_HallSensor_Start_DMA()
HAL_TIMEx_HallSensor_Stop_DMA()
46.2.4 Timer Complementary Output Compare functions
This section provides functions allowing to:
Start the Complementary Output Compare/PWM.
Stop the Complementary Output Compare/PWM.
Start the Complementary Output Compare/PWM and enable interrupts.
Stop the Complementary Output Compare/PWM and disable interrupts.
Start the Complementary Output Compare/PWM and enable DMA transfers.
Stop the Complementary Output Compare/PWM and disable DMA transfers.
This section contains the following APIs:
HAL_TIMEx_OCN_Start()
