ST STM32F2 User Manual

HAL TIM Generic Driver
UM1940
600/1371
DocID028236 Rev 2
contains the configuration information for TIM module.
sClearInputConfig: pointer to a
TIM_ClearInputConfigTypeDef structure that contains the
OCREF clear feature and parameters for the TIM peripheral.
Channel: specifies the TIM Channel. This parameter can be
one of the following values:
TIM_CHANNEL_1: TIM Channel 1 selected
TIM_CHANNEL_2: TIM Channel 2 selected
TIM_CHANNEL_3: TIM Channel 3 selected
TIM_CHANNEL_4: TIM Channel 4 selected
Return values
HAL: status
HAL_TIM_ConfigClockSource
Function name
HAL_StatusTypeDef HAL_TIM_ConfigClockSource
(TIM_HandleTypeDef * htim, TIM_ClockConfigTypeDef *
sClockSourceConfig)
Function description
Configures the clock source to be used.
Parameters
htim: pointer to a TIM_HandleTypeDef structure that
contains the configuration information for TIM module.
sClockSourceConfig: pointer to a TIM_ClockConfigTypeDef
structure that contains the clock source information for the
TIM peripheral.
Return values
HAL: status
HAL_TIM_ConfigTI1Input
Function name
HAL_StatusTypeDef HAL_TIM_ConfigTI1Input
(TIM_HandleTypeDef * htim, uint32_t TI1_Selection)
Function description
Selects the signal connected to the TI1 input: direct from
CH1_input or a XOR combination between CH1_input, CH2_input
& CH3_input.
Parameters
htim: pointer to a TIM_HandleTypeDef structure that
contains the configuration information for TIM module.
TI1_Selection: Indicate whether or not channel 1 is
connected to the output of a XOR gate. This parameter can
be one of the following values:
TIM_TI1SELECTION_CH1: The TIMx_CH1 pin is
connected to TI1 input
TIM_TI1SELECTION_XORCOMBINATION: The
TIMx_CH1, CH2 and CH3 pins are connected to the TI1
input (XOR combination)
Return values
HAL: status
HAL_TIM_SlaveConfigSynchronization
Function name
HAL_StatusTypeDef HAL_TIM_SlaveConfigSynchronization
(TIM_HandleTypeDef * htim, TIM_SlaveConfigTypeDef *
sSlaveConfig)
