HAL PCCARD Generic Driver
31 HAL PCCARD Generic Driver
31.1 PCCARD Firmware driver registers structures
31.1.1 PCCARD_HandleTypeDef
Data Fields
FSMC_PCCARD_TypeDef * Instance
FSMC_PCCARD_InitTypeDef Init
__IO HAL_PCCARD_StateTypeDef State
HAL_LockTypeDef Lock
Field Documentation
FSMC_PCCARD_TypeDef* PCCARD_HandleTypeDef::Instance
Register base address for PCCARD device
FSMC_PCCARD_InitTypeDef PCCARD_HandleTypeDef::Init
PCCARD device control configuration parameters
__IO HAL_PCCARD_StateTypeDef PCCARD_HandleTypeDef::State
PCCARD device access state
HAL_LockTypeDef PCCARD_HandleTypeDef::Lock
PCCARD Lock
31.2 PCCARD Firmware driver API description
31.2.1 How to use this driver
This driver is a generic layered driver which contains a set of APIs used to control
PCCARD/compact flash memories. It uses the FSMC layer functions to interface with
PCCARD devices. This driver is used for:
PCCARD/Compact Flash memory configuration sequence using the function
HAL_PCCARD_Init()/HAL_CF_Init() with control and timing parameters for both
common and attribute spaces.
Read PCCARD/Compact Flash memory maker and device IDs using the function
HAL_PCCARD_Read_ID()/HAL_CF_Read_ID(). The read information is stored in the
CompactFlash_ID structure declared by the function caller.
Access PCCARD/Compact Flash memory by read/write operations using the functions
HAL_PCCARD_Read_Sector()/ HAL_PCCARD_Write_Sector() -
HAL_CF_Read_Sector()/HAL_CF_Write_Sector(), to read/write sector.
Perform PCCARD/Compact Flash Reset chip operation using the function
HAL_PCCARD_Reset()/HAL_CF_Reset.
Perform PCCARD/Compact Flash erase sector operation using the function
HAL_PCCARD_Erase_Sector()/HAL_CF_Erase_Sector.
Read the PCCARD/Compact Flash status operation using the function
HAL_PCCARD_ReadStatus()/HAL_CF_ReadStatus().
You can monitor the PCCARD/Compact Flash device HAL state by calling the function
HAL_PCCARD_GetState()/HAL_CF_GetState()
