UM1940
HAL TIM Generic Driver
DocID028236 Rev 2
599/1371
TIM_CHANNEL_3: TIM Channel 3 selected
TIM_CHANNEL_4: TIM Channel 4 selected
Return values
HAL: status
HAL_TIM_IC_ConfigChannel
Function name
HAL_StatusTypeDef HAL_TIM_IC_ConfigChannel
(TIM_HandleTypeDef * htim, TIM_IC_InitTypeDef * sConfig,
uint32_t Channel)
Function description
Initializes the TIM Input Capture Channels according to the
specified parameters in the TIM_IC_InitTypeDef.
Parameters
htim: pointer to a TIM_HandleTypeDef structure that
contains the configuration information for TIM module.
sConfig: TIM Input Capture configuration structure
Channel: TIM Channels to be enabled. This parameter can
be one of the following values:
TIM_CHANNEL_1: TIM Channel 1 selected
TIM_CHANNEL_2: TIM Channel 2 selected
TIM_CHANNEL_3: TIM Channel 3 selected
TIM_CHANNEL_4: TIM Channel 4 selected
Return values
HAL: status
HAL_TIM_OnePulse_ConfigChannel
Function name
HAL_StatusTypeDef HAL_TIM_OnePulse_ConfigChannel
(TIM_HandleTypeDef * htim, TIM_OnePulse_InitTypeDef *
sConfig, uint32_t OutputChannel, uint32_t InputChannel)
Function description
Initializes the TIM One Pulse Channels according to the specified
parameters in the TIM_OnePulse_InitTypeDef.
Parameters
htim: pointer to a TIM_HandleTypeDef structure that
contains the configuration information for TIM module.
sConfig: TIM One Pulse configuration structure
OutputChannel: TIM Channels to be enabled. This
parameter can be one of the following values:
TIM_CHANNEL_1: TIM Channel 1 selected
TIM_CHANNEL_2: TIM Channel 2 selected
InputChannel: TIM Channels to be enabled. This parameter
can be one of the following values:
TIM_CHANNEL_1: TIM Channel 1 selected
TIM_CHANNEL_2: TIM Channel 2 selected
Return values
HAL: status
HAL_TIM_ConfigOCrefClear
Function name
HAL_StatusTypeDef HAL_TIM_ConfigOCrefClear
(TIM_HandleTypeDef * htim, TIM_ClearInputConfigTypeDef *
sClearInputConfig, uint32_t Channel)
Function description
Configures the OCRef clear feature.
Parameters
htim: pointer to a TIM_HandleTypeDef structure that
