26 HAL IRDA Generic Driver
26.1 IRDA Firmware driver registers structures
26.1.1 IRDA_InitTypeDef
Data Fields
uint32_t BaudRate
uint32_t WordLength
uint32_t Parity
uint32_t Mode
uint8_t Prescaler
uint32_t IrDAMode
Field Documentation
uint32_t IRDA_InitTypeDef::BaudRate
This member configures the IRDA communication baud rate. The baud rate is
computed using the following formula:IntegerDivider = ((PCLKx) / (8 * (hirda-
>Init.BaudRate)))FractionalDivider = ((IntegerDivider - ((uint32_t) IntegerDivider)) * 8)
+ 0.5
uint32_t IRDA_InitTypeDef::WordLength
Specifies the number of data bits transmitted or received in a frame. This parameter
can be a value of IRDA_Word_Length
uint32_t IRDA_InitTypeDef::Parity
Specifies the parity mode. This parameter can be a value of IRDA_Parity
Note:When parity is enabled, the computed parity is inserted at the MSB position of
the transmitted data (9th bit when the word length is set to 9 data bits; 8th bit when the
word length is set to 8 data bits).
uint32_t IRDA_InitTypeDef::Mode
Specifies wether the Receive or Transmit mode is enabled or disabled. This
parameter can be a value of IRDA_Mode
uint8_t IRDA_InitTypeDef::Prescaler
Specifies the Prescaler
uint32_t IRDA_InitTypeDef::IrDAMode
Specifies the IrDA mode This parameter can be a value of IRDA_Low_Power
26.1.2 IRDA_HandleTypeDef
Data Fields
USART_TypeDef * Instance
IRDA_InitTypeDef Init
uint8_t * pTxBuffPtr
uint16_t TxXferSize
__IO uint16_t TxXferCount
uint8_t * pRxBuffPtr
uint16_t RxXferSize
__IO uint16_t RxXferCount
DMA_HandleTypeDef * hdmatx
DMA_HandleTypeDef * hdmarx
HAL_LockTypeDef Lock
__IO HAL_IRDA_StateTypeDef gState
