uint32_t TIM_Encoder_InitTypeDef::EncoderMode
Specifies the active edge of the input signal. This parameter can be a value of
TIM_Encoder_Mode
uint32_t TIM_Encoder_InitTypeDef::IC1Polarity
Specifies the active edge of the input signal. This parameter can be a value of
TIM_Input_Capture_Polarity
uint32_t TIM_Encoder_InitTypeDef::IC1Selection
Specifies the input. This parameter can be a value of TIM_Input_Capture_Selection
uint32_t TIM_Encoder_InitTypeDef::IC1Prescaler
Specifies the Input Capture Prescaler. This parameter can be a value of
TIM_Input_Capture_Prescaler
uint32_t TIM_Encoder_InitTypeDef::IC1Filter
Specifies the input capture filter. This parameter can be a number between Min_Data
= 0x0 and Max_Data = 0xF
uint32_t TIM_Encoder_InitTypeDef::IC2Polarity
Specifies the active edge of the input signal. This parameter can be a value of
TIM_Input_Capture_Polarity
uint32_t TIM_Encoder_InitTypeDef::IC2Selection
Specifies the input. This parameter can be a value of TIM_Input_Capture_Selection
uint32_t TIM_Encoder_InitTypeDef::IC2Prescaler
Specifies the Input Capture Prescaler. This parameter can be a value of
TIM_Input_Capture_Prescaler
uint32_t TIM_Encoder_InitTypeDef::IC2Filter
Specifies the input capture filter. This parameter can be a number between Min_Data
= 0x0 and Max_Data = 0xF
45.1.6 TIM_ClockConfigTypeDef
Data Fields
uint32_t ClockSource
uint32_t ClockPolarity
uint32_t ClockPrescaler
uint32_t ClockFilter
Field Documentation
uint32_t TIM_ClockConfigTypeDef::ClockSource
TIM clock sources. This parameter can be a value of TIM_Clock_Source
uint32_t TIM_ClockConfigTypeDef::ClockPolarity
TIM clock polarity. This parameter can be a value of TIM_Clock_Polarity
uint32_t TIM_ClockConfigTypeDef::ClockPrescaler
TIM clock prescaler. This parameter can be a value of TIM_Clock_Prescaler
uint32_t TIM_ClockConfigTypeDef::ClockFilter
TIM clock filter. This parameter can be a number between Min_Data = 0x0 and
Max_Data = 0xF
45.1.7 TIM_ClearInputConfigTypeDef
Data Fields
uint32_t ClearInputState
uint32_t ClearInputSource
uint32_t ClearInputPolarity
uint32_t ClearInputPrescaler
uint32_t ClearInputFilter
