LL
GPIO Generic Driver
UM1940
936
/1371
DocID028236 Re
v 2
(GPIO_TypeDef * GP
IOx, uint32_t Pin)
Function description
Return gpio alternate f
unction of a ded
icated pin from
8 to 15 for a
dedicated port
.
Parameters
GPIOx:
GPIO Port
Pin:
This param
eter can be one of the f
ollowing values
:
LL_GPIO_PIN_8
LL_GPIO_PIN_9
LL_GPIO_PIN_10
LL_GPIO_PIN_11
LL_GPIO_PIN_12
LL_GPIO_PIN_13
LL_GPIO_PIN_14
LL_GPIO_PIN_15
Return values
Returned:
value ca
n be one of the f
ollowing values:
LL_GPIO_AF_0
LL_GPIO_AF_1
LL_GPIO_AF_2
LL_GPIO_AF_3
LL_GPIO_AF_4
LL_GPIO_AF_5
LL_GPIO_AF_6
LL_GPIO_AF_7
LL_GPIO_AF_8
LL_GPIO_AF_9
LL_GPIO_AF_10
LL_GPIO_AF_11
LL_GPIO_AF_12
LL_GPIO_AF_13
LL_GPIO_AF_14
LL_GPIO_AF_15
Notes
Possible values are f
rom
AF0 to AF15 depending on target.
Reference Manual t
o
LL API cross
reference:
AFRH AFSEL
y LL_GPIO_GetAFPin_8_
15
LL_GPIO_LockPin
Function name
__STATIC_INLINE v
oid LL_GPIO_Loc
kPin (GPIO_
TypeDef *
GPIOx, uint32_t PinM
ask)
Function description
Lock conf
iguration of several pins for a d
edicated port.
Parameters
GPIOx:
GPIO Port
PinMask:
T
his parameter c
an be a combination of
the
following values:
LL_GPIO_PIN_0
LL_GPIO_PIN_1
LL_GPIO_PIN_2
LL_GPIO_PIN_3
LL_GPIO_PIN_4
LL_GPIO_PIN_5
