Correspondence
between API registers
and API
low-layer driver functi
ons
UM1940
1334
/1371
DocID028236 Re
v 2
Register
Field
Function
RLR
RL
LL_IWDG_GetReloadCounter
LL_IWDG_SetReloadCounter
SR
PVU
LL_IWDG_IsActiveFlag_PVU
LL_IWDG_IsReady
RVU
LL_IWDG_IsActiveFlag_RVU
LL_IWDG_IsReady
71.12
PWR
Table 36: Correspondence between PWR registers and PWR low
-lay
er driver functions
Register
Field
Function
CR
CSBF
LL_PWR_ClearFlag_SB
C
W
UF
LL_PWR_ClearFlag_WU
DBP
LL_PWR_DisableBkUpAccess
LL_PWR_EnableBkUpAccess
LL_PWR_IsEnabledBkUpAccess
FPDS
LL_PWR_DisableFlashPowerDown
LL_PWR_EnableFlashPowerDown
LL_PWR_IsEnabledFlashPowerDown
LPDS
LL_PWR_GetPowerMode
LL_PWR_GetRegulModeDS
LL_PWR_SetPowerMode
LL_PWR_SetRegulModeDS
PDDS
LL_PWR_GetPowerMode
LL_PWR_SetPowerMode
PLS
LL_PWR_GetPVDLevel
LL_PWR_SetPVDLevel
PVDE
LL_PWR_DisablePVD
LL_PWR_EnablePVD
LL_PWR_IsEnabledPVD
CSR
BRE
LL_PWR_DisableBkUpRegulator
LL_PWR_EnableBkUpRegulator
LL_PWR_IsEnabledBkUpRegulator
BRR
LL_PWR_IsActiveFlag_BRR
EWUP
LL_PWR_DisableWakeUpPin
LL_PWR_EnableWakeUpPin
LL_PWR_IsEnabledWakeUpPin
1333
1335
