ST STM32F2 User Manual

UM1940
LL DAC Generic Driver
DocID028236 Rev 2
843/1371
(DAC_TypeDef * DACx, uint32_t DAC_Channel, uint32_t Data)
Function description
Set the data to be loaded in the data holding register in format 12
bits left alignment (MSB aligned on bit 15), for the selected DAC
channel.
Parameters
DACx: DAC instance
DAC_Channel: This parameter can be one of the following
values:
LL_DAC_CHANNEL_1
LL_DAC_CHANNEL_2
Data: Value between Min_Data=0x000 and
Max_Data=0xFFF
Return values
None:
Reference Manual to
LL API cross
reference:
DHR12L1 DACC1DHR LL_DAC_ConvertData12LeftAligned
DHR12L2 DACC2DHR LL_DAC_ConvertData12LeftAligned
LL_DAC_ConvertData8RightAligned
Function name
__STATIC_INLINE void LL_DAC_ConvertData8RightAligned
(DAC_TypeDef * DACx, uint32_t DAC_Channel, uint32_t Data)
Function description
Set the data to be loaded in the data holding register in format 8
bits left alignment (LSB aligned on bit 0), for the selected DAC
channel.
Parameters
DACx: DAC instance
DAC_Channel: This parameter can be one of the following
values:
LL_DAC_CHANNEL_1
LL_DAC_CHANNEL_2
Data: Value between Min_Data=0x00 and Max_Data=0xFF
Return values
None:
Reference Manual to
LL API cross
reference:
DHR8R1 DACC1DHR LL_DAC_ConvertData8RightAligned
DHR8R2 DACC2DHR LL_DAC_ConvertData8RightAligned
LL_DAC_ConvertDualData12RightAligned
Function name
__STATIC_INLINE void
LL_DAC_ConvertDualData12RightAligned (DAC_TypeDef *
DACx, uint32_t DataChannel1, uint32_t DataChannel2)
Function description
Set the data to be loaded in the data holding register in format 12
bits left alignment (LSB aligned on bit 0), for both DAC channels.
Parameters
DACx: DAC instance
DataChannel1: Value between Min_Data=0x000 and
Max_Data=0xFFF
DataChannel2: Value between Min_Data=0x000 and
Max_Data=0xFFF
Return values
None:
Reference Manual to
DHR12RD DACC1DHR
