ST STM32F2 User Manual

LL DAC Generic Driver
UM1940
844/1371
DocID028236 Rev 2
LL API cross
reference:
LL_DAC_ConvertDualData12RightAligned
DHR12RD DACC2DHR
LL_DAC_ConvertDualData12RightAligned
LL_DAC_ConvertDualData12LeftAligned
Function name
__STATIC_INLINE void
LL_DAC_ConvertDualData12LeftAligned (DAC_TypeDef *
DACx, uint32_t DataChannel1, uint32_t DataChannel2)
Function description
Set the data to be loaded in the data holding register in format 12
bits left alignment (MSB aligned on bit 15), for both DAC channels.
Parameters
DACx: DAC instance
DataChannel1: Value between Min_Data=0x000 and
Max_Data=0xFFF
DataChannel2: Value between Min_Data=0x000 and
Max_Data=0xFFF
Return values
None:
Reference Manual to
LL API cross
reference:
DHR12LD DACC1DHR
LL_DAC_ConvertDualData12LeftAligned
DHR12LD DACC2DHR
LL_DAC_ConvertDualData12LeftAligned
LL_DAC_ConvertDualData8RightAligned
Function name
__STATIC_INLINE void
LL_DAC_ConvertDualData8RightAligned (DAC_TypeDef *
DACx, uint32_t DataChannel1, uint32_t DataChannel2)
Function description
Set the data to be loaded in the data holding register in format 8
bits left alignment (LSB aligned on bit 0), for both DAC channels.
Parameters
DACx: DAC instance
DataChannel1: Value between Min_Data=0x00 and
Max_Data=0xFF
DataChannel2: Value between Min_Data=0x00 and
Max_Data=0xFF
Return values
None:
Reference Manual to
LL API cross
reference:
DHR8RD DACC1DHR
LL_DAC_ConvertDualData8RightAligned
DHR8RD DACC2DHR
LL_DAC_ConvertDualData8RightAligned
LL_DAC_RetrieveOutputData
Function name
__STATIC_INLINE uint32_t LL_DAC_RetrieveOutputData
(DAC_TypeDef * DACx, uint32_t DAC_Channel)
Function description
Retrieve output data currently generated for the selected DAC
channel.
Parameters
DACx: DAC instance
DAC_Channel: This parameter can be one of the following
values:
