LL_ADC_SetCommonPathInternalCh
__STATIC_INLINE void LL_ADC_SetCommonPathInternalCh
(ADC_Common_TypeDef * ADCxy_COMMON, uint32_t
PathInternal)
Set parameter common to several ADC: measurement path to
internal channels (VrefInt, temperature sensor, ...).
ADCxy_COMMON: ADC common instance (can be set
directly from CMSIS definition or by using helper macro
__LL_ADC_COMMON_INSTANCE() )
PathInternal: This parameter can be a combination of the
following values:
LL_ADC_PATH_INTERNAL_NONE
LL_ADC_PATH_INTERNAL_VREFINT
LL_ADC_PATH_INTERNAL_TEMPSENSOR
LL_ADC_PATH_INTERNAL_VBAT
One or several values can be selected. Example:
(LL_ADC_PATH_INTERNAL_VREFINT |
LL_ADC_PATH_INTERNAL_TEMPSENSOR)
Stabilization time of measurement path to internal channel:
After enabling internal paths, before starting ADC conversion,
a delay is required for internal voltage reference and
temperature sensor stabilization time. Refer to device
datasheet. Refer to literal
LL_ADC_DELAY_VREFINT_STAB_US. Refer to literal
LL_ADC_DELAY_TEMPSENSOR_STAB_US.
ADC internal channel sampling time constraint: For ADC
conversion of internal channels, a sampling time minimum
value is required. Refer to device datasheet.
Reference Manual to
LL API cross
reference:
CCR TSVREFE LL_ADC_SetCommonPathInternalCh
CCR VBATE LL_ADC_SetCommonPathInternalCh
LL_ADC_GetCommonPathInternalCh
__STATIC_INLINE uint32_t
LL_ADC_GetCommonPathInternalCh
(ADC_Common_TypeDef * ADCxy_COMMON)
Get parameter common to several ADC: measurement path to
internal channels (VrefInt, temperature sensor, ...).
ADCxy_COMMON: ADC common instance (can be set
directly from CMSIS definition or by using helper macro
__LL_ADC_COMMON_INSTANCE() )
Returned: value can be a combination of the following
values:
LL_ADC_PATH_INTERNAL_NONE
LL_ADC_PATH_INTERNAL_VREFINT
LL_ADC_PATH_INTERNAL_TEMPSENSOR
LL_ADC_PATH_INTERNAL_VBAT
