ST STM32F2 User Manual

UM1940
LL TIM Generic Driver
DocID028236 Rev 2
1179/1371
LL_TIM_OCIDLESTATE_HIGH
Return values
None:
Reference Manual to
LL API cross
reference:
CCMR1 CC1S LL_TIM_OC_ConfigOutput
CCMR1 CC2S LL_TIM_OC_ConfigOutput
CCMR2 CC3S LL_TIM_OC_ConfigOutput
CCMR2 CC4S LL_TIM_OC_ConfigOutput
CCER CC1P LL_TIM_OC_ConfigOutput
CCER CC2P LL_TIM_OC_ConfigOutput
CCER CC3P LL_TIM_OC_ConfigOutput
CCER CC4P LL_TIM_OC_ConfigOutput
CR2 OIS1 LL_TIM_OC_ConfigOutput
CR2 OIS2 LL_TIM_OC_ConfigOutput
CR2 OIS3 LL_TIM_OC_ConfigOutput
CR2 OIS4 LL_TIM_OC_ConfigOutput
LL_TIM_OC_SetMode
Function name
__STATIC_INLINE void LL_TIM_OC_SetMode (TIM_TypeDef *
TIMx, uint32_t Channel, uint32_t Mode)
Function description
Define the behavior of the output reference signal OCxREF from
which OCx and OCxN (when relevant) are derived.
Parameters
TIMx: Timer instance
Channel: This parameter can be one of the following values:
LL_TIM_CHANNEL_CH1
LL_TIM_CHANNEL_CH2
LL_TIM_CHANNEL_CH3
LL_TIM_CHANNEL_CH4
Mode: This parameter can be one of the following values:
LL_TIM_OCMODE_FROZEN
LL_TIM_OCMODE_ACTIVE
LL_TIM_OCMODE_INACTIVE
LL_TIM_OCMODE_TOGGLE
LL_TIM_OCMODE_FORCED_INACTIVE
LL_TIM_OCMODE_FORCED_ACTIVE
LL_TIM_OCMODE_PWM1
LL_TIM_OCMODE_PWM2
Return values
None:
Reference Manual to
LL API cross
reference:
CCMR1 OC1M LL_TIM_OC_SetMode
CCMR1 OC2M LL_TIM_OC_SetMode
CCMR2 OC3M LL_TIM_OC_SetMode
CCMR2 OC4M LL_TIM_OC_SetMode
LL_TIM_OC_GetMode
Function name
__STATIC_INLINE uint32_t LL_TIM_OC_GetMode
(TIM_TypeDef * TIMx, uint32_t Channel)
Function description
Get the output compare mode of an output channel.
Parameters
TIMx: Timer instance
Channel: This parameter can be one of the following values:
