ST STM32F2 User Manual

LL TIM Generic Driver
UM1940
1190/1371
DocID028236 Rev 2
reference:
LL_TIM_IC_Config
Function name
__STATIC_INLINE void LL_TIM_IC_Config (TIM_TypeDef *
TIMx, uint32_t Channel, uint32_t Configuration)
Function description
Configure input channel.
Parameters
TIMx: Timer instance
Channel: This parameter can be one of the following values:
LL_TIM_CHANNEL_CH1
LL_TIM_CHANNEL_CH2
LL_TIM_CHANNEL_CH3
LL_TIM_CHANNEL_CH4
Configuration: This parameter must be a combination of all
the following values:
LL_TIM_ACTIVEINPUT_DIRECTTI or
LL_TIM_ACTIVEINPUT_INDIRECTTI or
LL_TIM_ACTIVEINPUT_TRC
LL_TIM_ICPSC_DIV1 or ... or LL_TIM_ICPSC_DIV8
LL_TIM_IC_FILTER_FDIV1 or ... or
LL_TIM_IC_FILTER_FDIV32_N8
LL_TIM_IC_POLARITY_RISING or
LL_TIM_IC_POLARITY_FALLING or
LL_TIM_IC_POLARITY_BOTHEDGE
Return values
None:
Reference Manual to
LL API cross
reference:
CCMR1 CC1S LL_TIM_IC_Config
CCMR1 IC1PSC LL_TIM_IC_Config
CCMR1 IC1F LL_TIM_IC_Config
CCMR1 CC2S LL_TIM_IC_Config
CCMR1 IC2PSC LL_TIM_IC_Config
CCMR1 IC2F LL_TIM_IC_Config
CCMR2 CC3S LL_TIM_IC_Config
CCMR2 IC3PSC LL_TIM_IC_Config
CCMR2 IC3F LL_TIM_IC_Config
CCMR2 CC4S LL_TIM_IC_Config
CCMR2 IC4PSC LL_TIM_IC_Config
CCMR2 IC4F LL_TIM_IC_Config
CCER CC1P LL_TIM_IC_Config
CCER CC1NP LL_TIM_IC_Config
CCER CC2P LL_TIM_IC_Config
CCER CC2NP LL_TIM_IC_Config
CCER CC3P LL_TIM_IC_Config
CCER CC3NP LL_TIM_IC_Config
CCER CC4P LL_TIM_IC_Config
CCER CC4NP LL_TIM_IC_Config
LL_TIM_IC_SetActiveInput
Function name
__STATIC_INLINE void LL_TIM_IC_SetActiveInput
(TIM_TypeDef * TIMx, uint32_t Channel, uint32_t
ICActiveInput)
