ST STM32F2 User Manual

UM1940
LL TIM Generic Driver
DocID028236 Rev 2
1195/1371
CCER CC3NP LL_TIM_IC_GetPolarity
CCER CC4P LL_TIM_IC_GetPolarity
CCER CC4NP LL_TIM_IC_GetPolarity
LL_TIM_IC_EnableXORCombination
Function name
__STATIC_INLINE void LL_TIM_IC_EnableXORCombination
(TIM_TypeDef * TIMx)
Function description
Connect the TIMx_CH1, CH2 and CH3 pins to the TI1 input (XOR
combination).
Parameters
TIMx: Timer instance
Return values
None:
Notes
Macro IS_TIM_XOR_INSTANCE(TIMx) can be used to check
whether or not a timer instance provides an XOR input.
Reference Manual to
LL API cross
reference:
CR2 TI1S LL_TIM_IC_EnableXORCombination
LL_TIM_IC_DisableXORCombination
Function name
__STATIC_INLINE void LL_TIM_IC_DisableXORCombination
(TIM_TypeDef * TIMx)
Function description
Disconnect the TIMx_CH1, CH2 and CH3 pins from the TI1 input.
Parameters
TIMx: Timer instance
Return values
None:
Notes
Macro IS_TIM_XOR_INSTANCE(TIMx) can be used to check
whether or not a timer instance provides an XOR input.
Reference Manual to
LL API cross
reference:
CR2 TI1S LL_TIM_IC_DisableXORCombination
LL_TIM_IC_IsEnabledXORCombination
Function name
__STATIC_INLINE uint32_t
LL_TIM_IC_IsEnabledXORCombination (TIM_TypeDef * TIMx)
Function description
Indicates whether the TIMx_CH1, CH2 and CH3 pins are
connectected to the TI1 input.
Parameters
TIMx: Timer instance
Return values
State: of bit (1 or 0).
Notes
Macro IS_TIM_XOR_INSTANCE(TIMx) can be used to check
whether or not a timer instance provides an XOR input.
Reference Manual to
LL API cross
reference:
CR2 TI1S LL_TIM_IC_IsEnabledXORCombination
