UM1940
1328
/1371
DocID028236 Re
v 2
71.8
GPIO
Table 32: Correspondence between GPIO registers and GPIO
low
-la
y
e
r driver functions
Register
Field
Function
AFRH
AFSELy
LL_GPIO_GetAFPin_8_15
LL_GPIO_SetAFPin_8_15
AFRL
AFSELy
LL_GPIO_GetAFPin_0_7
LL_GPIO_SetAFPin_0_7
BSRR
BRy
LL_GPIO_ResetOutputPin
BSy
LL_GPIO_SetOutputPin
IDR
IDy
LL_GPIO_IsInputPinSet
LL_GPIO_ReadInputPort
LCKR
LCKK
LL_GPIO_IsAnyPinLocked
LL_GPIO_LockPin
LCKy
LL_GPIO_IsPinLocked
MODER
MODEy
LL_GPIO_GetPinMode
LL_GPIO_SetPinMode
ODR
ODy
LL_GPIO_IsOutputPinSet
LL_GPIO_ReadOutputPort
LL_GPIO_TogglePin
LL_GPIO_WriteOutputPort
OSPEEDR
OSPEEDy
LL_GPIO_GetPinSpeed
LL_GPIO_SetPinSpeed
OTYPER
OTy
LL_GPIO_GetPinOutputType
LL_GPIO_SetPinOutputType
PUPDR
PUPDy
LL_GPIO_GetPinPull
LL_GPIO_SetPinPull
71.9
I2C
Table 33: Correspondence between I2C registers and I2C low-la
y
er driver func
tions
Register
Field
Function
CCR
CCR
LL_I2C_ConfigSpeed
LL_I2C_GetClockPeriod
LL_I2C_SetClockPeriod
DUTY
LL_I2C_ConfigSpeed
LL_I2C_GetDutyCycle
1327
1329
