UM1940
Correspondence
between API reg
isters and API
low-layer driver functi
ons
DocID028236 Re
v 2
1329
/1371
Register
Field
Function
LL_I2C_SetDutyCycle
FS
LL_I2C_ConfigSpeed
LL_I2C_GetClockSpeedMode
LL_I2C_SetClockSpeedMode
CR1
ACK
LL_I2C_AcknowledgeNextData
ALERT
LL_I2C_DisableSMBusAlert
LL_I2C_EnableSMBusAlert
LL_I2C_IsEnabledSMBusAlert
ENARP
LL_I2C_GetMode
LL_I2C_SetMode
ENGC
LL_I2C_DisableGeneralCall
LL_I2C_EnableGeneralCall
LL_I2C_IsEnabledGeneralCall
ENPEC
LL_I2C_DisableSMBusPEC
LL_I2C_EnableSMBusPEC
LL_I2C_IsEnabledSMBusPEC
NOSTRETCH
LL_I2C_DisableClockStretching
LL_I2C_EnableClockStretching
LL_I2C_IsEnabledClockStretching
PE
LL_I2C_ClearFlag_STOP
LL_I2C_Disable
LL_I2C_Enable
LL_I2C_IsEnabled
PEC
LL_I2C_DisableSMBusPECCompare
LL_I2C_EnableSMBusPECCompare
LL_I2C_IsEnabledSMBusPECCompare
POS
LL_I2C_DisableBitPOS
LL_I2C_EnableBitPOS
LL_I2C_IsEnabledBitPOS
SMBTYPE
LL_I2C_GetMode
LL_I2C_SetMode
SMBUS
LL_I2C_GetMode
LL_I2C_SetMode
START
LL_I2C_GenerateStartCondition
STOP
LL_I2C_GenerateStopCondition
SWRST
LL_I2C_DisableReset
1328
1330
