ST STM32F2 User Manual

UM1940
HAL TIM Extension Driver
DocID028236 Rev 2
629/1371
46 HAL TIM Extension Driver
46.1 TIMEx Firmware driver registers structures
46.1.1 TIM_HallSensor_InitTypeDef
Data Fields
uint32_t IC1Polarity
uint32_t IC1Prescaler
uint32_t IC1Filter
uint32_t Commutation_Delay
Field Documentation
uint32_t TIM_HallSensor_InitTypeDef::IC1Polarity
Specifies the active edge of the input signal. This parameter can be a value of
TIM_Input_Capture_Polarity
uint32_t TIM_HallSensor_InitTypeDef::IC1Prescaler
Specifies the Input Capture Prescaler. This parameter can be a value of
TIM_Input_Capture_Prescaler
uint32_t TIM_HallSensor_InitTypeDef::IC1Filter
Specifies the input capture filter. This parameter can be a number between Min_Data
= 0x0 and Max_Data = 0xF
uint32_t TIM_HallSensor_InitTypeDef::Commutation_Delay
Specifies the pulse value to be loaded into the Capture Compare Register. This
parameter can be a number between Min_Data = 0x0000 and Max_Data = 0xFFFF
46.1.2 TIM_MasterConfigTypeDef
Data Fields
uint32_t MasterOutputTrigger
uint32_t MasterSlaveMode
Field Documentation
uint32_t TIM_MasterConfigTypeDef::MasterOutputTrigger
Trigger output (TRGO) selection. This parameter can be a value of
TIM_Master_Mode_Selection
uint32_t TIM_MasterConfigTypeDef::MasterSlaveMode
Master/slave mode selection. This parameter can be a value of
TIM_Master_Slave_Mode
46.1.3 TIM_BreakDeadTimeConfigTypeDef
Data Fields
uint32_t OffStateRunMode
uint32_t OffStateIDLEMode
uint32_t LockLevel
uint32_t DeadTime
uint32_t BreakState
uint32_t BreakPolarity
uint32_t AutomaticOutput
