Field Documentation
uint32_t TIM_BreakDeadTimeConfigTypeDef::OffStateRunMode
TIM off state in run mode. This parameter can be a value of
TIM_OSSR_Off_State_Selection_for_Run_mode_state
uint32_t TIM_BreakDeadTimeConfigTypeDef::OffStateIDLEMode
TIM off state in IDLE mode. This parameter can be a value of
TIM_OSSI_Off_State_Selection_for_Idle_mode_state
uint32_t TIM_BreakDeadTimeConfigTypeDef::LockLevel
TIM Lock level. This parameter can be a value of TIM_Lock_level
uint32_t TIM_BreakDeadTimeConfigTypeDef::DeadTime
TIM dead Time. This parameter can be a number between Min_Data = 0x00 and
Max_Data = 0xFF
uint32_t TIM_BreakDeadTimeConfigTypeDef::BreakState
TIM Break State. This parameter can be a value of
TIM_Break_Input_enable_disable
uint32_t TIM_BreakDeadTimeConfigTypeDef::BreakPolarity
TIM Break input polarity. This parameter can be a value of TIM_Break_Polarity
uint32_t TIM_BreakDeadTimeConfigTypeDef::AutomaticOutput
TIM Automatic Output Enable state. This parameter can be a value of
TIM_AOE_Bit_Set_Reset
46.2 TIMEx Firmware driver API description
46.2.1 TIMER Extended features
The Timer Extension features include:
1. Complementary outputs with programmable dead-time for :
Input Capture
Output Compare
PWM generation (Edge and Center-aligned Mode)
One-pulse mode output
2. Synchronization circuit to control the timer with external signals and to interconnect
several timers together.
3. Break input to put the timer output signals in reset state or in a known state.
4. Supports incremental (quadrature) encoder and hall-sensor circuitry for positioning
purposes
46.2.2 How to use this driver
1. Initialize the TIM low level resources by implementing the following functions
depending from feature used :
Complementary Output Compare : HAL_TIM_OC_MspInit()
Complementary PWM generation : HAL_TIM_PWM_MspInit()
Complementary One-pulse mode output : HAL_TIM_OnePulse_MspInit()
Hall Sensor output : HAL_TIM_HallSensor_MspInit()
2. Initialize the TIM low level resources :
a. Enable the TIM interface clock using __TIMx_CLK_ENABLE();
b. TIM pins configuration
Enable the clock for the TIM GPIOs using the following function:
__GPIOx_CLK_ENABLE();
Configure these TIM pins in Alternate function mode using HAL_GPIO_Init();
3. The external Clock can be configured, if needed (the default clock is the internal clock
from the APBx), using the following function: HAL_TIM_ConfigClockSource, the clock
configuration should be done before any start function.
