ST STM32F2 User Manual

UM1940
LL TIM Generic Driver
DocID028236 Rev 2
1189/1371
be between 0x00000000 and 0xFFFFFFFF.
Macro IS_TIM_32B_COUNTER_INSTANCE(TIMx) can be
used to check whether or not a timer instance supports a 32
bits counter.
Macro IS_TIM_CC2_INSTANCE(TIMx) can be used to check
whether or not output channel 2 is supported by a timer
instance.
Reference Manual to
LL API cross
reference:
CCR2 CCR2 LL_TIM_OC_GetCompareCH2
LL_TIM_OC_GetCompareCH3
Function name
__STATIC_INLINE uint32_t LL_TIM_OC_GetCompareCH3
(TIM_TypeDef * TIMx)
Function description
Get compare value (TIMx_CCR3) set for output channel 3.
Parameters
TIMx: Timer instance
Return values
CompareValue: (between Min_Data=0 and
Max_Data=65535)
Notes
In 32-bit timer implementations returned compare value can
be between 0x00000000 and 0xFFFFFFFF.
Macro IS_TIM_32B_COUNTER_INSTANCE(TIMx) can be
used to check whether or not a timer instance supports a 32
bits counter.
Macro IS_TIM_CC3_INSTANCE(TIMx) can be used to check
whether or not output channel 3 is supported by a timer
instance.
Reference Manual to
LL API cross
reference:
CCR3 CCR3 LL_TIM_OC_GetCompareCH3
LL_TIM_OC_GetCompareCH4
Function name
__STATIC_INLINE uint32_t LL_TIM_OC_GetCompareCH4
(TIM_TypeDef * TIMx)
Function description
Get compare value (TIMx_CCR4) set for output channel 4.
Parameters
TIMx: Timer instance
Return values
CompareValue: (between Min_Data=0 and
Max_Data=65535)
Notes
In 32-bit timer implementations returned compare value can
be between 0x00000000 and 0xFFFFFFFF.
Macro IS_TIM_32B_COUNTER_INSTANCE(TIMx) can be
used to check whether or not a timer instance supports a 32
bits counter.
Macro IS_TIM_CC4_INSTANCE(TIMx) can be used to check
whether or not output channel 4 is supported by a timer
instance.
Reference Manual to
LL API cross
CCR4 CCR4 LL_TIM_OC_GetCompareCH4
