ST STM32F2 User Manual

UM1940
HAL TIM Generic Driver
DocID028236 Rev 2
575/1371
uint32_t TIM_OnePulse_InitTypeDef::OCIdleState
Specifies the TIM Output Compare pin state during Idle state. This parameter can be a
value of TIM_Output_Compare_Idle_State
Note:This parameter is valid only for TIM1 and TIM8.
uint32_t TIM_OnePulse_InitTypeDef::OCNIdleState
Specifies the TIM Output Compare pin state during Idle state. This parameter can be a
value of TIM_Output_Compare_N_Idle_State
Note:This parameter is valid only for TIM1 and TIM8.
uint32_t TIM_OnePulse_InitTypeDef::ICPolarity
Specifies the active edge of the input signal. This parameter can be a value of
TIM_Input_Capture_Polarity
uint32_t TIM_OnePulse_InitTypeDef::ICSelection
Specifies the input. This parameter can be a value of TIM_Input_Capture_Selection
uint32_t TIM_OnePulse_InitTypeDef::ICFilter
Specifies the input capture filter. This parameter can be a number between Min_Data
= 0x0 and Max_Data = 0xF
45.1.4 TIM_IC_InitTypeDef
Data Fields
uint32_t ICPolarity
uint32_t ICSelection
uint32_t ICPrescaler
uint32_t ICFilter
Field Documentation
uint32_t TIM_IC_InitTypeDef::ICPolarity
Specifies the active edge of the input signal. This parameter can be a value of
TIM_Input_Capture_Polarity
uint32_t TIM_IC_InitTypeDef::ICSelection
Specifies the input. This parameter can be a value of TIM_Input_Capture_Selection
uint32_t TIM_IC_InitTypeDef::ICPrescaler
Specifies the Input Capture Prescaler. This parameter can be a value of
TIM_Input_Capture_Prescaler
uint32_t TIM_IC_InitTypeDef::ICFilter
Specifies the input capture filter. This parameter can be a number between Min_Data
= 0x0 and Max_Data = 0xF
45.1.5 TIM_Encoder_InitTypeDef
Data Fields
uint32_t EncoderMode
uint32_t IC1Polarity
uint32_t IC1Selection
uint32_t IC1Prescaler
uint32_t IC1Filter
uint32_t IC2Polarity
uint32_t IC2Selection
uint32_t IC2Prescaler
uint32_t IC2Filter
Field Documentation
