ST STM32F2 User Manual

UM1940
LL TIM Generic Driver
DocID028236 Rev 2
1163/1371
Field Documentation
uint32_t LL_TIM_OC_InitTypeDef::OCMode
Specifies the output mode. This parameter can be a value of
TIM_LL_EC_OCMODE.This feature can be modified afterwards using unitary function
LL_TIM_OC_SetMode().
uint32_t LL_TIM_OC_InitTypeDef::OCState
Specifies the TIM Output Compare state. This parameter can be a value of
TIM_LL_EC_OCSTATE.This feature can be modified afterwards using unitary
functions LL_TIM_CC_EnableChannel() or LL_TIM_CC_DisableChannel().
uint32_t LL_TIM_OC_InitTypeDef::OCNState
Specifies the TIM complementary Output Compare state. This parameter can be a
value of TIM_LL_EC_OCSTATE.This feature can be modified afterwards using
unitary functions LL_TIM_CC_EnableChannel() or LL_TIM_CC_DisableChannel().
uint32_t LL_TIM_OC_InitTypeDef::CompareValue
Specifies the Compare value to be loaded into the Capture Compare Register. This
parameter can be a number between Min_Data=0x0000 and Max_Data=0xFFFF.This
feature can be modified afterwards using unitary function
LL_TIM_OC_SetCompareCHx (x=1..6).
uint32_t LL_TIM_OC_InitTypeDef::OCPolarity
Specifies the output polarity. This parameter can be a value of
TIM_LL_EC_OCPOLARITY.This feature can be modified afterwards using unitary
function LL_TIM_OC_SetPolarity().
uint32_t LL_TIM_OC_InitTypeDef::OCNPolarity
Specifies the complementary output polarity. This parameter can be a value of
TIM_LL_EC_OCPOLARITY.This feature can be modified afterwards using unitary
function LL_TIM_OC_SetPolarity().
uint32_t LL_TIM_OC_InitTypeDef::OCIdleState
Specifies the TIM Output Compare pin state during Idle state. This parameter can be a
value of TIM_LL_EC_OCIDLESTATE.This feature can be modified afterwards using
unitary function LL_TIM_OC_SetIdleState().
uint32_t LL_TIM_OC_InitTypeDef::OCNIdleState
Specifies the TIM Output Compare pin state during Idle state. This parameter can be a
value of TIM_LL_EC_OCIDLESTATE.This feature can be modified afterwards using
unitary function LL_TIM_OC_SetIdleState().
67.1.3 LL_TIM_IC_InitTypeDef
Data Fields
uint32_t ICPolarity
uint32_t ICActiveInput
uint32_t ICPrescaler
uint32_t ICFilter
Field Documentation
uint32_t LL_TIM_IC_InitTypeDef::ICPolarity
Specifies the active edge of the input signal. This parameter can be a value of
TIM_LL_EC_IC_POLARITY.This feature can be modified afterwards using unitary
function LL_TIM_IC_SetPolarity().
uint32_t LL_TIM_IC_InitTypeDef::ICActiveInput
Specifies the input. This parameter can be a value of
TIM_LL_EC_ACTIVEINPUT.This feature can be modified afterwards using unitary
function LL_TIM_IC_SetActiveInput().
uint32_t LL_TIM_IC_InitTypeDef::ICPrescaler
Specifies the Input Capture Prescaler. This parameter can be a value of
