ST STM32F2 User Manual

UM1940
HAL DCMI Generic Driver
DocID028236 Rev 2
177/1371
14 HAL DCMI Generic Driver
14.1 DCMI Firmware driver registers structures
14.1.1 DCMI_CodesInitTypeDef
Data Fields
uint8_t FrameStartCode
uint8_t LineStartCode
uint8_t LineEndCode
uint8_t FrameEndCode
Field Documentation
uint8_t DCMI_CodesInitTypeDef::FrameStartCode
Specifies the code of the frame start delimiter.
uint8_t DCMI_CodesInitTypeDef::LineStartCode
Specifies the code of the line start delimiter.
uint8_t DCMI_CodesInitTypeDef::LineEndCode
Specifies the code of the line end delimiter.
uint8_t DCMI_CodesInitTypeDef::FrameEndCode
Specifies the code of the frame end delimiter.
14.1.2 DCMI_InitTypeDef
Data Fields
uint32_t SynchroMode
uint32_t PCKPolarity
uint32_t VSPolarity
uint32_t HSPolarity
uint32_t CaptureRate
uint32_t ExtendedDataMode
DCMI_CodesInitTypeDef SyncroCode
uint32_t JPEGMode
Field Documentation
uint32_t DCMI_InitTypeDef::SynchroMode
Specifies the Synchronization Mode: Hardware or Embedded. This parameter can be
a value of DCMI_Synchronization_Mode
uint32_t DCMI_InitTypeDef::PCKPolarity
Specifies the Pixel clock polarity: Falling or Rising. This parameter can be a value of
DCMI_PIXCK_Polarity
uint32_t DCMI_InitTypeDef::VSPolarity
Specifies the Vertical synchronization polarity: High or Low. This parameter can be a
value of DCMI_VSYNC_Polarity
uint32_t DCMI_InitTypeDef::HSPolarity
Specifies the Horizontal synchronization polarity: High or Low. This parameter can be
a value of DCMI_HSYNC_Polarity
uint32_t DCMI_InitTypeDef::CaptureRate
Specifies the frequency of frame capture: All, 1/2 or 1/4. This parameter can be a
value of DCMI_Capture_Rate
