UM1940
Correspondence
between API reg
isters and API
low-layer driver functi
ons
DocID028236 Re
v 2
1333
/1371
Register
Field
Function
LL_I2S_SetTransferMode
I2SE
LL_I2S_Disable
LL_I2S_Enable
LL_I2S_IsEnabled
I2SMOD
LL_I2S_Enable
I2SSTD
LL_I2S_GetStandard
LL_I2S_SetStandard
PCMSYNC
LL_I2S_GetStandard
LL_I2S_SetStandard
I2SPR
I2SDIV
LL_I2S_GetPrescalerLinear
LL_I2S_SetPrescalerLinear
MCKOE
LL_I2S_DisableMasterClock
LL_I2S_EnableMasterClock
LL_I2S_IsEnabledMasterClock
ODD
LL_I2S_GetPrescalerParity
LL_I2S_SetPrescalerParity
SR
BSY
LL_I2S_IsActiveFlag_BSY
CHSIDE
LL_I2S_IsActiveFlag_CHSIDE
FRE
LL_I2S_ClearFlag_FRE
LL_I2S_IsActiveFlag_FRE
OVR
LL_I2S_ClearFlag_OVR
LL_I2S_IsActiveFlag_OVR
RXNE
LL_I2S_IsActiveFlag_RXNE
TXE
LL_I2S_IsActiveFlag_TXE
UDR
LL_I2S_ClearFlag_UDR
LL_I2S_IsActiveFlag_UDR
71.11
IWDG
Table 35: Correspondence between IWDG registers and IWDG low-la
y
e
r driver functions
Register
Field
Function
KR
KEY
LL_IWDG_DisableWriteAccess
LL_IWDG_Enable
LL_IWDG_EnableWriteAccess
LL_IWDG_ReloadCounter
PR
PR
LL_IWDG_GetPrescaler
LL_IWDG_SetPrescaler
1332
1334
