ST STM32F2 User Manual

UM1940
LL ADC Generic Driver
DocID028236 Rev 2
743/1371
Notes
For devices with feature oversampling: Oversampling can
increase data width, function for extended range may be
needed: LL_ADC_INJ_ReadConversionData32.
Reference Manual to
LL API cross
reference:
JDR1 JDATA LL_ADC_INJ_ReadConversionData12
JDR2 JDATA LL_ADC_INJ_ReadConversionData12
JDR3 JDATA LL_ADC_INJ_ReadConversionData12
JDR4 JDATA LL_ADC_INJ_ReadConversionData12
LL_ADC_INJ_ReadConversionData10
Function name
__STATIC_INLINE uint16_t
LL_ADC_INJ_ReadConversionData10 (ADC_TypeDef * ADCx,
uint32_t Rank)
Function description
Get ADC group injected conversion data, range fit for ADC
resolution 10 bits.
Parameters
ADCx: ADC instance
Rank: This parameter can be one of the following values:
LL_ADC_INJ_RANK_1
LL_ADC_INJ_RANK_2
LL_ADC_INJ_RANK_3
LL_ADC_INJ_RANK_4
Return values
Value: between Min_Data=0x000 and Max_Data=0x3FF
Notes
For devices with feature oversampling: Oversampling can
increase data width, function for extended range may be
needed: LL_ADC_INJ_ReadConversionData32.
Reference Manual to
LL API cross
reference:
JDR1 JDATA LL_ADC_INJ_ReadConversionData10
JDR2 JDATA LL_ADC_INJ_ReadConversionData10
JDR3 JDATA LL_ADC_INJ_ReadConversionData10
JDR4 JDATA LL_ADC_INJ_ReadConversionData10
LL_ADC_INJ_ReadConversionData8
Function name
__STATIC_INLINE uint8_t
LL_ADC_INJ_ReadConversionData8 (ADC_TypeDef * ADCx,
uint32_t Rank)
Function description
Get ADC group injected conversion data, range fit for ADC
resolution 8 bits.
Parameters
ADCx: ADC instance
Rank: This parameter can be one of the following values:
LL_ADC_INJ_RANK_1
LL_ADC_INJ_RANK_2
LL_ADC_INJ_RANK_3
LL_ADC_INJ_RANK_4
Return values
Value: between Min_Data=0x00 and Max_Data=0xFF
Notes
For devices with feature oversampling: Oversampling can
increase data width, function for extended range may be
needed: LL_ADC_INJ_ReadConversionData32.
Reference Manual to
JDR1 JDATA LL_ADC_INJ_ReadConversionData8
