ST STM32F2 User Manual

UM1940
LL USART Generic Driver
DocID028236 Rev 2
1251/1371
Function description
Configure Clock signal format (Phase Polarity and choice about
output of last bit clock pulse)
Parameters
USARTx: USART Instance
Phase: This parameter can be one of the following values:
LL_USART_PHASE_1EDGE
LL_USART_PHASE_2EDGE
Polarity: This parameter can be one of the following values:
LL_USART_POLARITY_LOW
LL_USART_POLARITY_HIGH
LBCPOutput: This parameter can be one of the following
values:
LL_USART_LASTCLKPULSE_NO_OUTPUT
LL_USART_LASTCLKPULSE_OUTPUT
Return values
None:
Notes
Macro IS_USART_INSTANCE(USARTx) can be used to
check whether or not Synchronous mode is supported by the
USARTx instance.
Call of this function is equivalent to following function call
sequence : Clock Phase configuration using
LL_USART_SetClockPhase() functionClock Polarity
configuration using LL_USART_SetClockPolarity()
functionOutput of Last bit Clock pulse configuration using
LL_USART_SetLastClkPulseOutput() function
Reference Manual to
LL API cross
reference:
CR2 CPHA LL_USART_ConfigClock
CR2 CPOL LL_USART_ConfigClock
CR2 LBCL LL_USART_ConfigClock
LL_USART_EnableSCLKOutput
Function name
__STATIC_INLINE void LL_USART_EnableSCLKOutput
(USART_TypeDef * USARTx)
Function description
Enable Clock output on SCLK pin.
Parameters
USARTx: USART Instance
Return values
None:
Notes
Macro IS_USART_INSTANCE(USARTx) can be used to
check whether or not Synchronous mode is supported by the
USARTx instance.
Reference Manual to
LL API cross
reference:
CR2 CLKEN LL_USART_EnableSCLKOutput
LL_USART_DisableSCLKOutput
Function name
__STATIC_INLINE void LL_USART_DisableSCLKOutput
(USART_TypeDef * USARTx)
Function description
Disable Clock output on SCLK pin.
Parameters
USARTx: USART Instance
