ST STM32F2 User Manual

HAL CAN Generic Driver
UM1940
106/1371
DocID028236 Rev 2
uint32_t CAN_InitTypeDef::TXFP
Enable or disable the transmit FIFO priority. This parameter can be set to ENABLE or
DISABLE
8.1.2 CAN_FilterConfTypeDef
Data Fields
uint32_t FilterIdHigh
uint32_t FilterIdLow
uint32_t FilterMaskIdHigh
uint32_t FilterMaskIdLow
uint32_t FilterFIFOAssignment
uint32_t FilterNumber
uint32_t FilterMode
uint32_t FilterScale
uint32_t FilterActivation
uint32_t BankNumber
Field Documentation
uint32_t CAN_FilterConfTypeDef::FilterIdHigh
Specifies the filter identification number (MSBs for a 32-bit configuration, first one for a
16-bit configuration). This parameter must be a number between Min_Data = 0x0000
and Max_Data = 0xFFFF
uint32_t CAN_FilterConfTypeDef::FilterIdLow
Specifies the filter identification number (LSBs for a 32-bit configuration, second one
for a 16-bit configuration). This parameter must be a number between Min_Data =
0x0000 and Max_Data = 0xFFFF
uint32_t CAN_FilterConfTypeDef::FilterMaskIdHigh
Specifies the filter mask number or identification number, according to the mode
(MSBs for a 32-bit configuration, first one for a 16-bit configuration). This parameter
must be a number between Min_Data = 0x0000 and Max_Data = 0xFFFF
uint32_t CAN_FilterConfTypeDef::FilterMaskIdLow
Specifies the filter mask number or identification number, according to the mode
(LSBs for a 32-bit configuration, second one for a 16-bit configuration). This parameter
must be a number between Min_Data = 0x0000 and Max_Data = 0xFFFF
uint32_t CAN_FilterConfTypeDef::FilterFIFOAssignment
Specifies the FIFO (0 or 1) which will be assigned to the filter. This parameter can be
a value of CAN_filter_FIFO
uint32_t CAN_FilterConfTypeDef::FilterNumber
Specifies the filter which will be initialized. This parameter must be a number between
Min_Data = 0 and Max_Data = 27
uint32_t CAN_FilterConfTypeDef::FilterMode
Specifies the filter mode to be initialized. This parameter can be a value of
CAN_filter_mode
uint32_t CAN_FilterConfTypeDef::FilterScale
Specifies the filter scale. This parameter can be a value of CAN_filter_scale
uint32_t CAN_FilterConfTypeDef::FilterActivation
Enable or disable the filter. This parameter can be set to ENABLE or DISABLE.
uint32_t CAN_FilterConfTypeDef::BankNumber
Select the start slave bank filter. This parameter must be a number between Min_Data
= 0 and Max_Data = 28
