ST STM32F2

HAL TIM Extension Driver
UM1940
644/1371
DocID028236 Rev 2
HSE_RTC clock (HSE divided by a programmable
prescaler)
Return values
HAL: status
HAL_TIMEx_CommutationCallback
Function name
void HAL_TIMEx_CommutationCallback (TIM_HandleTypeDef
* htim)
Function description
Hall commutation changed callback in non blocking mode.
Parameters
htim: pointer to a TIM_HandleTypeDef structure that
contains the configuration information for TIM module.
Return values
None:
HAL_TIMEx_BreakCallback
Function name
void HAL_TIMEx_BreakCallback (TIM_HandleTypeDef * htim)
Function description
Hall Break detection callback in non blocking mode.
Parameters
htim: pointer to a TIM_HandleTypeDef structure that
contains the configuration information for TIM module.
Return values
None:
TIMEx_DMACommutationCplt
Function name
void TIMEx_DMACommutationCplt (DMA_HandleTypeDef *
hdma)
Function description
TIM DMA Commutation callback.
Parameters
hdma: pointer to a DMA_HandleTypeDef structure that
contains the configuration information for the specified DMA
module.
Return values
None:
HAL_TIMEx_HallSensor_GetState
Function name
HAL_TIM_StateTypeDef HAL_TIMEx_HallSensor_GetState
(TIM_HandleTypeDef * htim)
Function description
Return the TIM Hall Sensor interface state.
Parameters
htim: pointer to a TIM_HandleTypeDef structure that
contains the configuration information for TIM module.
Return values
HAL: state
46.3 TIMEx Firmware driver defines
46.3.1 TIMEx
TIM Remap
TIM_TIM2_TIM8_TRGO
