ST STM32F2 User Manual

LL TIM Generic Driver
UM1940
1180/1371
DocID028236 Rev 2
LL_TIM_CHANNEL_CH1
LL_TIM_CHANNEL_CH2
LL_TIM_CHANNEL_CH3
LL_TIM_CHANNEL_CH4
Return values
Returned: value can be one of the following values:
LL_TIM_OCMODE_FROZEN
LL_TIM_OCMODE_ACTIVE
LL_TIM_OCMODE_INACTIVE
LL_TIM_OCMODE_TOGGLE
LL_TIM_OCMODE_FORCED_INACTIVE
LL_TIM_OCMODE_FORCED_ACTIVE
LL_TIM_OCMODE_PWM1
LL_TIM_OCMODE_PWM2
Reference Manual to
LL API cross
reference:
CCMR1 OC1M LL_TIM_OC_GetMode
CCMR1 OC2M LL_TIM_OC_GetMode
CCMR2 OC3M LL_TIM_OC_GetMode
CCMR2 OC4M LL_TIM_OC_GetMode
LL_TIM_OC_SetPolarity
Function name
__STATIC_INLINE void LL_TIM_OC_SetPolarity (TIM_TypeDef
* TIMx, uint32_t Channel, uint32_t Polarity)
Function description
Set the polarity of an output channel.
Parameters
TIMx: Timer instance
Channel: This parameter can be one of the following values:
LL_TIM_CHANNEL_CH1
LL_TIM_CHANNEL_CH1N
LL_TIM_CHANNEL_CH2
LL_TIM_CHANNEL_CH2N
LL_TIM_CHANNEL_CH3
LL_TIM_CHANNEL_CH3N
LL_TIM_CHANNEL_CH4
Polarity: This parameter can be one of the following values:
LL_TIM_OCPOLARITY_HIGH
LL_TIM_OCPOLARITY_LOW
Return values
None:
Reference Manual to
LL API cross
reference:
CCER CC1P LL_TIM_OC_SetPolarity
CCER CC1NP LL_TIM_OC_SetPolarity
CCER CC2P LL_TIM_OC_SetPolarity
CCER CC2NP LL_TIM_OC_SetPolarity
CCER CC3P LL_TIM_OC_SetPolarity
CCER CC3NP LL_TIM_OC_SetPolarity
CCER CC4P LL_TIM_OC_SetPolarity
LL_TIM_OC_GetPolarity
Function name
__STATIC_INLINE uint32_t LL_TIM_OC_GetPolarity
(TIM_TypeDef * TIMx, uint32_t Channel)
Function description
Get the polarity of an output channel.
