Correspondence
between API registers
and API
low-layer driver functi
ons
UM1940
1352
/1371
DocID028236 Re
v 2
Register
Field
Function
LL_TIM_CC_IsEnabledChannel
CC2NE
LL_TIM_CC_DisableChannel
LL_TIM_CC_EnableChannel
LL_TIM_CC_IsEnabledChannel
CC2NP
LL_TIM_IC_Config
LL_TIM_IC_GetPolarity
LL_TIM_IC_SetPolarity
LL_TIM_OC_GetPolarity
LL_TIM_OC_SetPolarity
CC2P
LL_TIM_IC_Config
LL_TIM_IC_GetPolarity
LL_TIM_IC_SetPolarity
LL_TIM_OC_ConfigOutput
LL_TIM_OC_GetPolarity
LL_TIM_OC_SetPolarity
CC3E
LL_TIM_CC_DisableChannel
LL_TIM_CC_EnableChannel
LL_TIM_CC_IsEnabledChannel
CC3NE
LL_TIM_CC_DisableChannel
LL_TIM_CC_EnableChannel
LL_TIM_CC_IsEnabledChannel
CC3NP
LL_TIM_IC_Config
LL_TIM_IC_GetPolarity
LL_TIM_IC_SetPolarity
LL_TIM_OC_GetPolarity
LL_TIM_OC_SetPolarity
CC3P
LL_TIM_IC_Config
LL_TIM_IC_GetPolarity
LL_TIM_IC_SetPolarity
LL_TIM_OC_ConfigOutput
LL_TIM_OC_GetPolarity
LL_TIM_OC_SetPolarity
CC4E
LL_TIM_CC_DisableChannel
LL_TIM_CC_EnableChannel
LL_TIM_CC_IsEnabledChannel
CC4NP
LL_TIM_IC_Config
1351
