UM1940
1326
/1371
DocID028236 Re
v 2
Register
Field
Function
CDMEIF2
LL_DMA_ClearFlag_DME2
CDMEIF3
LL_DMA_ClearFlag_DME3
CFEIF0
LL_DMA_ClearFlag_FE0
CFEIF1
LL_DMA_ClearFlag_FE1
CFEIF2
LL_DMA_ClearFlag_FE2
CFEIF3
LL_DMA_ClearFlag_FE3
CHTIF0
LL_DMA_ClearFlag_HT0
CHTIF1
LL_DMA_ClearFlag_HT1
CHTIF2
LL_DMA_ClearFlag_HT2
CHTIF3
LL_DMA_ClearFlag_HT3
CTCIF0
LL_DMA_ClearFlag_TC0
CTCIF1
LL_DMA_ClearFlag_TC1
CTCIF2
LL_DMA_ClearFlag_TC2
CTCIF3
LL_DMA_ClearFlag_TC3
CTEIF0
LL_DMA_ClearFlag_TE0
CTEIF1
LL_DMA_ClearFlag_TE1
CTEIF2
LL_DMA_ClearFlag_TE2
CTEIF3
LL_DMA_ClearFlag_TE3
LISR
DMEIF0
LL_DMA_IsActiveFlag_DME0
DMEIF1
LL_DMA_IsActiveFlag_DME1
DMEIF2
LL_DMA_IsActiveFlag_DME2
DMEIF3
LL_DMA_IsActiveFlag_DME3
FEIF0
LL_DMA_IsActiveFlag_FE0
FEIF1
LL_DMA_IsActiveFlag_FE1
FEIF2
LL_DMA_IsActiveFlag_FE2
FEIF3
LL_DMA_IsActiveFlag_FE3
HTIF0
LL_DMA_IsActiveFlag_HT0
HTIF1
LL_DMA_IsActiveFlag_HT1
HTIF2
LL_DMA_IsActiveFlag_HT2
HTIF3
LL_DMA_IsActiveFlag_HT3
TCIF0
LL_DMA_IsActiveFlag_TC0
TCIF1
LL_DMA_IsActiveFlag_TC1
TCIF2
LL_DMA_IsActiveFlag_TC2
TCIF3
LL_DMA_IsActiveFlag_TC3
TEIF0
LL_DMA_IsActiveFlag_TE0
TEIF1
LL_DMA_IsActiveFlag_TE1
1325
1327
