UM1940
Correspondence
between API reg
isters and API
low-layer driver functi
ons
DocID028236 Re
v 2
1325
/1371
Register
Field
Function
CFEIF6
LL_DMA_ClearFlag_FE6
CFEIF7
LL_DMA_ClearFlag_FE7
CHTIF4
LL_DMA_ClearFlag_HT4
CHTIF5
LL_DMA_ClearFlag_HT5
CHTIF6
LL_DMA_ClearFlag_HT6
CHTIF7
LL_DMA_ClearFlag_HT7
CTCIF4
LL_DMA_ClearFlag_TC4
CTCIF5
LL_DMA_ClearFlag_TC5
CTCIF6
LL_DMA_ClearFlag_TC6
CTCIF7
LL_DMA_ClearFlag_TC7
CTEIF4
LL_DMA_ClearFlag_TE4
CTEIF5
LL_DMA_ClearFlag_TE5
CTEIF6
LL_DMA_ClearFlag_TE6
CTEIF7
LL_DMA_ClearFlag_TE7
HISR
DMEIF0
LL_DMA_IsActiveFlag_DME5
DMEIF4
LL_DMA_IsActiveFlag_DME4
DMEIF6
LL_DMA_IsActiveFlag_DME6
DMEIF7
LL_DMA_IsActiveFlag_DME7
FEIF0
LL_DMA_IsActiveFlag_FE5
FEIF4
LL_DMA_IsActiveFlag_FE4
FEIF6
LL_DMA_IsActiveFlag_FE6
FEIF7
LL_DMA_IsActiveFlag_FE7
HTIF0
LL_DMA_IsActiveFlag_HT5
HTIF4
LL_DMA_IsActiveFlag_HT4
HTIF6
LL_DMA_IsActiveFlag_HT6
HTIF7
LL_DMA_IsActiveFlag_HT7
TCIF0
LL_DMA_IsActiveFlag_TC5
TCIF4
LL_DMA_IsActiveFlag_TC4
TCIF6
LL_DMA_IsActiveFlag_TC6
TCIF7
LL_DMA_IsActiveFlag_TC7
TEIF0
LL_DMA_IsActiveFlag_TE5
TEIF4
LL_DMA_IsActiveFlag_TE4
TEIF6
LL_DMA_IsActiveFlag_TE6
TEIF7
LL_DMA_IsActiveFlag_TE7
LIFCR
CDMEIF0
LL_DMA_ClearFlag_DME0
CDMEIF1
LL_DMA_ClearFlag_DME1
1324
1326
