UM1940
1324
/1371
DocID028236 Re
v 2
Register
Field
Function
PFCTRL
LL_DMA_ConfigTransfer
LL_DMA_GetMode
LL_DMA_SetMode
PINC
LL_DMA_ConfigTransfer
LL_DMA_GetPeriphIncMode
LL_DMA_SetPeriphIncMode
PINCOS
LL_DMA_GetIncOffsetSize
LL_DMA_SetIncOffsetSiz
e
PL
LL_DMA_ConfigTransfer
LL_DMA_GetStreamPriorityLevel
LL_DMA_SetStreamPriorityLevel
PSIZE
LL_DMA_ConfigTransfer
LL_DMA_GetPeriphSize
LL_DMA_SetPeriphSize
TCIE
LL_DMA_DisableIT_TC
LL_DMA_EnableIT_TC
LL_DMA_IsEnabledIT_TC
TEIE
LL_DMA_DisableIT_TE
LL_DMA_EnableIT_TE
LL_DMA_IsEnabledIT_TE
FCR
DMDIS
LL_DMA_ConfigFifo
LL_DMA_DisableFifoMode
LL_DMA_EnableFifoMode
FEIE
LL_DMA_DisableIT_FE
LL_DMA_EnableIT_FE
LL_DMA_IsEnabledIT_FE
FS
LL_DMA_GetFIFOStatus
FTH
LL_DMA_ConfigFifo
LL_DMA_GetFIFOThreshold
LL_DMA_SetFIFOThreshold
HIFCR
CDMEIF4
LL_DMA_ClearFlag_DME4
CDMEIF5
LL_DMA_ClearFlag_DME5
CDMEIF6
LL_DMA_ClearFlag_DME6
CDMEIF7
LL_DMA_ClearFlag_DME7
CFEIF4
LL_DMA_ClearFlag_FE4
CFEIF5
LL_DMA_ClearFlag_FE5
1323
1325
