Correspondence
between API registers
and API
low-layer driver functi
ons
UM1940
1342
/1371
DocID028236 Re
v 2
Register
Field
Function
COE
LL_RTC_CAL_GetOutputFreq
LL_RTC_CAL_SetOutputFreq
COSEL
LL_RTC_CAL_GetOutputFreq
LL_RTC_CAL_SetOutputFreq
DCE
LL_RTC_CAL_DisableCoarseDigital
LL_RTC_CAL_EnableCoarseDigital
FMT
LL_RTC_GetHourFormat
LL_RTC_SetHourFormat
OSEL
LL_RTC_GetAlarmOutEvent
LL_RTC_SetAlarmOutEvent
POL
LL_RTC_GetOutputPolarity
LL_RTC_SetOutputPolarity
REFCKON
LL_RTC_DisableRefClock
LL_RTC_EnableRefClock
SUB1H
LL_RTC_TIME_DecHour
TSE
LL_RTC_TS_Disable
LL_RTC_TS_Enable
TSEDGE
LL_RTC_TS_GetActiveEdge
LL_RTC_TS_SetActiveEdge
TSIE
LL_RTC_DisableIT_TS
LL_RTC_EnableIT_TS
LL_RTC_IsEnabledIT_TS
W
UCKSEL
LL_RTC_WAKEUP_GetClock
LL_RTC_WAKEUP_SetClock
W
UTE
LL_RTC_WAKEUP_Disable
LL_RTC_WAKEUP_Enable
LL_RTC_WAKEUP_IsEnabled
W
UTIE
LL_RTC_DisableIT_WUT
LL_RTC_EnableIT_WUT
LL_RTC_IsEnabledIT_WUT
DR
DT
LL_RTC_DATE_Config
LL_RTC_DATE_Get
LL_RTC_DATE_GetDay
LL_RTC_DATE_SetDay
DU
LL_RTC_DATE_Config
LL_RTC_DATE_Get
1341
