UM1940
Correspondence
between API reg
isters and API
low-layer driver functi
ons
DocID028236 Re
v 2
1347
/1371
Register
Field
Function
LL_SPI_SetMode
SSM
LL_SPI_GetNSSMode
LL_SPI_SetNSSMode
CR2
ERRIE
LL_SPI_DisableIT_ERR
LL_SPI_EnableIT_ERR
LL_SPI_IsEnabledIT_ERR
FRF
LL_SPI_GetStandard
LL_SPI_SetStandard
RXDMAEN
LL_SPI_DisableDMAReq_RX
LL_SPI_EnableDMAReq_RX
LL_SPI_IsEnabledDMAReq_RX
RXNEIE
LL_SPI_DisableIT_RXNE
LL_SPI_EnableIT_RXNE
LL_SPI_IsEnabledIT_RXNE
SSOE
LL_SPI_GetNSSMode
LL_SPI_SetNSSMode
TXDMAEN
LL_SPI_DisableDMAReq_TX
LL_SPI_EnableDMAReq_TX
LL_SPI_IsEnabledDMAReq_TX
TXEIE
LL_SPI_DisableIT_TXE
LL_SPI_EnableIT_TXE
LL_SPI_IsEnabledIT_TXE
CRCPR
CRCPOLY
LL_SPI_GetCRCPolynomial
LL_SPI_SetCRCPolynomial
DR
DR
LL_SPI_DMA_GetRegAddr
LL_SPI_ReceiveData16
LL_SPI_ReceiveData8
LL_SPI_TransmitData16
LL_SPI_TransmitData8
RXCRCR
RXCRC
LL_SPI_GetRxCRC
SR
BSY
LL_SPI_IsActiveFlag_BSY
CRCERR
LL_SPI_ClearFlag_CRCERR
LL_SPI_IsActiveFlag_CRCERR
FRE
LL_SPI_ClearFlag_FRE
LL_SPI_IsActiveFlag_FRE
MODF
LL_SPI_ClearFlag_MODF
1346
1348
