ST STM32F2 User Manual

LL ADC Generic Driver
UM1940
784/1371
DocID028236 Rev 2
LL_ADC_GROUP_REGULAR))
__LL_ADC_ANALOGWD_SET_TH
RESHOLD_RESOLUTION
Description:
Helper macro to set the value of ADC analog
watchdog threshold high or low in function of
ADC resolution, when ADC resolution is
different of 12 bits.
Parameters:
__ADC_RESOLUTION__: This parameter can
be one of the following values:
LL_ADC_RESOLUTION_12B
LL_ADC_RESOLUTION_10B
LL_ADC_RESOLUTION_8B
LL_ADC_RESOLUTION_6B
__AWD_THRESHOLD__: Value between
Min_Data=0x000 and Max_Data=0xFFF
Return value:
Value: between Min_Data=0x000 and
Max_Data=0xFFF
Notes:
To be used with function
LL_ADC_SetAnalogWDThresholds(). Example,
with a ADC resolution of 8 bits, to set the value
of analog watchdog threshold high (on 8 bits):
LL_ADC_SetAnalogWDThresholds (< ADCx
param>,
__LL_ADC_ANALOGWD_SET_THRESHOLD_
RESOLUTION(LL_ADC_RESOLUTION_8B,
<threshold_value_8_bits>) );
__LL_ADC_ANALOGWD_GET_TH
RESHOLD_RESOLUTION
Description:
Helper macro to get the value of ADC analog
watchdog threshold high or low in function of
ADC resolution, when ADC resolution is
different of 12 bits.
Parameters:
__ADC_RESOLUTION__: This parameter can
be one of the following values:
LL_ADC_RESOLUTION_12B
LL_ADC_RESOLUTION_10B
LL_ADC_RESOLUTION_8B
LL_ADC_RESOLUTION_6B
__AWD_THRESHOLD_12_BITS__: Value
between Min_Data=0x000 and
Max_Data=0xFFF
Return value:
Value: between Min_Data=0x000 and
Max_Data=0xFFF
