Smart Help to request technical support or instrument service directly from the instrument
•
Barcode scanner for tracking plates or TaqMan
™
Array Cards
Features of each instrument
Feature
QuantStudio
™
6 Pro System QuantStudio
™
7 Pro System
Filter set
[1]
Coupled five-color filter set Decoupled six-by-six color filter set
VeriFlex
™
Zones
[2]
Three VeriFlex
™
Zones Six VeriFlex
™
Zones
TaqMan
™
Array Card
block
— Available
Security, Auditing, and
E‑signature (SAE) v2.0
module
— Available
[3]
[1]
S
ee “System dyes” on page 16.
[2]
See “VeriFlex
™
Zones” on page 18.
[3]
See Chapter 9, “Use the instrument with the Security, Auditing, and E‑signature (SAE) v2.0 module”.
Instrument filt
ers and supported dyes
System dyes
The QuantStudio
™
6 Pro Real-Time PCR System has a coupled five-color filter set.
The QuantStudio
™
7 Pro Real-Time PCR System has a decoupled six-by-six color filter set.
For more information about available spectral dye calibration kits, contact Support.
Peak filter Color
Filter wavelength (nm)
[1]
System dyes Example custom dyes
Excitation Emission
x1-m1 Blue 470 ± 15 520 ± 15
FAM
™
dye, SYBR
GREEN
™
dye
SYT09
x2-m2 Green 520 ± 10 558 ± 11 VIC
™
dye
JOE
™
dye, HEX
™
dye,
TET
™
dye
[2]
x3-m3 Yellow 550 ± 11 586 ± 10
NED
™
dye, TAMRA
™
dye, ABY
™
dye
Cy
®
3 dye
x4-m4 Orange 580 ± 10 623 ± 14 ROX
™
dye, JUN
™
dye Texas Red
™
dye
x5-m5 Red 640 ± 10 682 ± 14
MUSTANG PURPLE
™
dye, Cy
®
5
LIZ
™
dye
x6-m6 Deep-Red 662 ± 10 711 ± 12 None
[3]
Cy
®
5.5 dye
[1]
T
he central wavelengths are the optimized wavelengths.
[2]
The HEX
™
dye and TET
™
dye from Thermo Fisher Scientific fall within the emission wavelength range of the system, therefore they
can be added and adapted for use on the instrument.
[3]
This filter set currently does not support any dyes supplied by Thermo Fisher Scientific.
Chapter 1 P
roduct information
Instrument hardware description
1
16
QuantStudio
™
6 Pro Real-Time PCR System and QuantStudio
™
7 Pro Real-Time PCR System User Guide
