20-7
IM DL950-02EN
20.3 Accessing the Instrument from a PC (FTP
Server)
This section explains the following settings for accessing the instrument from a PC on a network:
Items Common to Scope Mode and Recorder Mode
• User name
• Password
• Timeout
• Starting an FTP client
► “FTP Server (FTP/Web Server)” in the Features Guide
UTILITY Network Menu
1.
On the waveform screen’s MENU, tap OTHERS > UTILITY, or press UTILITY.
2.
Tap Network, or press the soft key. The following screen appears.
Select Network.
See “Configuring the FTP Server.”
(For information on the Web server, see
section 20.4.)
Configure the TCP/IP settings
► sec. 20.2
Configure mail settings. ► sec. 20.6
Configure network printing. ► sec. 20.8
Configure the network drive. ► sec. 20.5
Configure SNTP. ► sec. 20.7
Configure the TCP/IP settings
► sec. 20.2 (/C60 option)
Configuring the FTP Server (FTP/Web Server)
3.
Tap FTP/Web Server, or press the soft key. The following screen appears.
Set the user name (up to 15 characters).
Set the password (up to 15 characters).
Set the timeout (30 to 3600).
Applies the settings
Selects 1G or 10G (displayed for the /C60 option)
Note
If you set the user name to “anonymous,” you can connect to the instrument without entering a password.
Starting an FTP Client
Start an FTP client on a PC. Enter the user name and password that you have set on the
instrument’s FTP/Web Server screen shown above, and connect to the instrument.
To Next Page
