2.7 Configuring Frequency, Revolution, Period, Duty
Cycle, Power Supply Frequency, Pulse Width,
Pulse Integration, and Velocity Measurements
This section explains the following settings for frequency, revolution, period, duty cycle, power
supply frequency, pulse width, pulse integration, and velocity measurements:
Scope Mode
Turning waveform input or and off
Display label
FV setup (measurement items)
Input condition
Filter (bandwidth limit, digital filter)
Display setup (display group)
Zoom method (DIV/SPAN) switching
Vertical zoom (vertical zoom, offset), upper and lower display range limits
Sample rate
Linear scaling
Vertical scale
Vertical position
Recorder Mode
Turning waveform input or and off
Display label
FV setup (measurement items)
Input condition
Filter (bandwidth limit, digital filter)
Display setup (display group)
Upper and lower limits of the display range
Sample interval
Linear scaling
Vertical scale
Vertical position
► “Frequency Measurement” in the Features Guide
