21-4

IM DL950-02EN

21.2 Configuring Master Settings (/C40 option)

This section explains the following settings that are necessary for this instrument to be selected as

a master unit in IEEE1588.

Items Common to Scope Mode and Recorder Mode

• Master mode

• Clock source

• Priority1, Priority2

• Leap second

► “IEEE1588 Setup (IEEE1588 Setup)” in the Features Guide

Utility System Config Time Sync Menu

On the waveform screen’s MENU, tap OTHERS > UTILITY, or press UTILITY.

Tap System Config, or press the soft key.

Tap Time Sync, or press the soft key. The following screen appears.

Select System

Config.

Select

Time Sync.

Set the

synchronization mode

to IEEE1588.

See “Configuring

IEEE1588 Settings.”
