Chapter 21

Time Synchronization

Main Control Areas Used in This Chapter

You can also use the touch panel.

Jog dial

Arrow keys

Soft keys

Touch panel

UTILITY key

Operation Modes Applicable to the Sections in This Chapter

: Applicable, -: Not applicable

Section Scope Mode Recorder Mode

21.1 Setting Time Synchronization Mode

ü ü

21.2 Configuring Master Settings (/C40 option)

ü ü

* The settings may vary depending on the operation mode.
