8.2 Searching for Events
This section explains the following settings for searching for events):
Items Common to Scope Mode and Recorder Mode
• Search type
• Search source
Event number
► “Event Search (Event)” in the Features Guide
SEARCH Event Menu
1.
On the waveform screen’s MENU, tap ANALYSIS > SEARCH, or press SHIFT+ZOOM
(SEARCH).
2.
Set Type to Event.
See “Executing a Search.”
Set Type to Event.
Set the event number (1-100).
Configure the search result display window
(zoom window) ► sec. 8.1
Executing a Search (Execute)
3.
Tap Execute, or press the soft key. The instrument executes the search.
