2.6 Configuring Acceleration Measurements
This section explains the following settings for acceleration measurements:
Scope Mode
• Turning waveform input or and off
• Display label
• Input coupling
• Turning the bias current supply to the acceleration sensor on and off
• Filter (bandwidth limit, digital filter)
• Display setup (display group)
• Zoom method (DIV/SPAN) switching
• Vertical zoom (vertical zoom, offset), upper and lower display range limits
• Gain
• Acceleration sensor sensitivity
• Sample rate
• Acceleration unit
• Vertical position
Recorder Mode
• Turning waveform input or and off
• Display label
• Input coupling
• Turning the bias current supply to the acceleration sensor on and off
• Filter (bandwidth limit, digital filter)
• Display setup (display group)
• Upper and lower limits of the display range
• Gain
• Acceleration sensor sensitivity
• Sample interval
• Acceleration unit
• Vertical position
► “Acceleration Measurement” in the Features Guide
