102 ZXP Series 9 Card Printer Service Manual P1086708-001
Operation
Loading the Laminate
Step 11. Rotate the core to adjust the laminate overhang. Stop when the end of the laminate
is just beyond the lip of the cassette, as shown below.
Important • Check for laminate overhang any time the locking lever is pressed or the
cassette is removed.
0 - 0.5 mm
0 - 1/32"
0 - 0.5 mm
0 - 1/32"
