366 ZXP Series 9 Card Printer Service Manual P1086708-001
Replacement Procedures for the Laminator
Procedures: Motor and Plate Assembly
Step 3. With a TORX T10 driver, remove the four screws (circled below) holding the motor
and plate assembly in place.
Step 4. Carefully free the motor and plate assembly from the frame. Ensure that all gears
and shafts remain in place.
