Zebra ZXP 9 Series User Manual

88 ZXP Series 9 Card Printer Service Manual P1086708-001
Operation
Operator Control Panel (OCP)
Print Test Cards Menu
Main Menu
Print Test Cards Menu
UP DOWN
SELECT /
PRINT
RETURN
> CARD TYPE
Selects the type of cards being printed on (varying types of
PVC, Composite, etc.).
> COUNT
Selects the number of cards to be printed (1, 5, 10, 25, 50,
75, 100)
GRADIENT BOXES Prints a test card with varying gradient boxes.
DENSITY SETUP
MONOCHROME ONLY
Prints a test card with varying color densities.
Prints a test card with monochrome bitmap elements. Only
works when monochrome ribbon is installed.
> SIDES Selects single-sided or double-sided printing.

Zebra ZXP 9 Series Specifications

General

Resolution	300 dpi
Card Capacity Output	100 cards
Memory	64 MB
Interface	USB, Ethernet
Operating Humidity	20% to 80% non-condensing
Print Technology	Dye Sublimation
Print Speed YMCK	Up to 190 cards/hour
Card Capacity Input	100 cards
Card Sizes	CR-80 ISO 7810
Connectivity	USB, Ethernet
Operating System	Windows, Linux
Options	Magnetic stripe encoding
Power Requirements	100-240V AC, 50/60Hz
Operating Temperature	15°C to 35°C
Card Thickness	10-40 mil
