Installation System Manual
Unpacking and internal transport CRIUS II
4
3 Put suitable support plates below the cabinet (approx. 1 cm thick). The
support plates make sure that it will be possible to insert the load plates
of the lift truck below the cabinet frame.
4 Lower the cabinet onto the support plates
5 On both sides of the cabinet, insert the load plates of the lift trucks below
the cabinet frame
6 Use the load belts and tighten the load trucks to the cabinet. Position
the load straps as low as possible.
7 Use the lift trucks to lift the cabinet to transport height
8 Remove the support plates
9 Carefully transport the cabinet to the required location
NOTE:
It is also possible to mount the lift trucks to the cabinet frame by insert-
ing two screws into the mounting holes at the cabinet frame.
