Maintenance System Manual
Glove box CRIUS II
6
6.9.3 Cleaning the pump filter
1 Open the corresponding door to access the glove box pump
Fig. 6-15 Glove box pump
2 Open the KF clamp at the glove box pump
3 Remove the filter
Fig. 6-16 Removing the pump filter
A Position of the filter
BKF clamp
CPump
4 Blow out the filter grid with compressed air and clean it with alcohol
WARNING! Hazardous process gases.
The vacuum system may contain hazardous gases which can be detri-
mental for your health.
Always wear a gas mask, gloves and industrial clothing with long
sleeves when opening parts of the vacuum system. Read the safety data
sheets for the gases and follow all instructions.
