3.10.2 Adjacent channel power measurement function settings
Device messages for adjacent channel power measurement settings are shown in Table 3.10.2-1.
Table 3.10.2-1 Adjacent channel power measurement function setting messages
Function Command Query Response Remarks
Measure Adjacent Channel
Power
MEAS ADJ
MEAS? ADJ
mode
: Measurement mode
=
MOD | TOTAL | INBAND |
BOTHSIDE
num:
Reference carrier number
MEAS ADJ,EXE
MEAS ADJ,mode
MEAS ADJ,num
Measure Adjacent Channel
Power
MEAS OFF MEAS? OFF
ACP Reference
MADJMOD mode
MADJMOD?
mode
mode
: Measurement mode
=
MOD | TOTAL | INBAND |
BOTHSIDE
MADJMOD num
num
num:
Reference carrier number
Noise Cancel
NOISECANCEL on_off NOISECANCEL? on_off
on_off:
= ON | OFF
ACP Channel Bandwidth
ADJCHBW freq
ADJCHBW?
freq
ACP Carrier BW
ADJINBW freq ADJINBW? freq
ACP In Band Center
ADJCARRIERCNT freq
ADJCARRIERCNT?
freq
ACP Carrier Number
ADJCARRIERNUM num ADJCARRIERNUM? num
num:
Carrier number
ACP Carrier Spacing
ADJCARRIERSPAC freq
ADJCARRIERSPAC?
freq
freq:
Carrier spacing
ACP Offset-1
ADJOFFSET1 on_off ADJOFFSET1? on_off
ACP Offset-2
ADJOFFSET2 on_off
ADJOFFSET2?
on_off
ACP Offset-3
ADJOFFSET3 on_off ADJOFFSET3? on_off
