2.5 Signal Search
2-163
2
SCPI Device Message Details
2.5 Signal Search
Table 2.5-1 lists device messages for signal search.
Table 2.5-1 Device messages for signal search
Function
Device Message
Peak Search
:CALCulate:MARKer[1]|2|3|4|5|6|7|8|9|10:MAXimum
Next Peak Search
:CALCulate:MARKer[1]|2|3|4|5|6|7|8|9|10:MAXimum:NEXT
Power Peak Search
:CALCulate:MARKer[1]|2|3|4|5|6|7|8|9|10:MAXimum:POWer
Next Power
Peak Search
:CALCulate:MARKer[1]|2|3|4|5|6|7|8|9|10:MAXimum:POWer:NEXT
Minimum Search
:CALCulate:MARKer[1]|2|3|4|5|6|7|8|9|10:MINimum
Next Minimum
Search
:CALCulate:MARKer[1]|2|3|4|5|6|7|8|9|10:MINimum:NEXT
Marker Peak
Excursion
:CALCulate:MARKer:PEAK:RESolution|EXCursion <rel_ampl>|<percent>
:CALCulate:MARKer:PEAK:RESolution|EXCursion?
Peak Search
Threshold Level
:CALCulate:MARKer:PEAK:THReshold <ampl>
:CALCulate:MARKer:PEAK:THReshold?
Peak Search
Threshold Level
On/Off
:CALCulate:MARKer:PEAK:THReshold:STATe ON|OFF|1|0
:CALCulate:MARKer:PEAK:THReshold:STATe?
Peak Search Mode
:CALCulate:MARKer:PEAK:THReshold:MODE ABOVe|BELow
:CALCulate:MARKer:PEAK:THReshold:MODE?
All Peak Search and
Query
:CALCulate:DATA:PEAKs[:LOGarithmic]?
<threshold>,<resolution>[,<sort>]
Search Peaks Sort Y
:CALCulate:MARKer:PEAK:SORT:Y
Search Peaks Sort X
:CALCulate:MARKer:PEAK:SORT:X
Search Peaks
Number
:CALCulate:MARKer:PEAK:SORT:COUNt <integer>
:CALCulate:MARKer:PEAK:SORT:COUNt?
