Port to Port testPort to Port test
Loopback testLoopback test
Frame Size (Bytes)Frame Size (Bytes)
Traffic ProfileTraffic Profile
LatencyLatency
BurstBurst
CreditCredit
When a test is selected, the test setup screen including the setup parameters related to
the test can be used. Similarly, the test results include only the test selected at Test
Selection.
Test Mode DescriptionsTest Mode Descriptions
In this test mode, the facing test of Network Master and the FC instrument is
performed.
This test is used when testing network by reflecting traffic back to the Network
Master. This requires a device to reflect the traffic back e.g. a second Network
Master.
There are three methods to specify the size of the fiber channel frame sent
during the test.
Frame Size (Bytes) is a byte length from header to CRC. It does not include SOF and
EOF.
User defined
Check the check box and select the following frame size:
6464, 128128, 256256, 512512, 768768, 10241024, 12801280, 21402140, and 21682168 to 32403240 (Set the frame size
using the field at the right bottom.)
Stepped
Set Start frame sizeStart frame size, End frame sizeEnd frame size and Step frame sizeStep frame size. The frame size is
started from the value set at Start frame sizeStart frame size, and increased/decreased until
the value set at End frame sizeEnd frame size at intervals of the value set at Step frame sizeStep frame size.
